(NOTE 1)Load and line regulation are specified at constant junction temperature. Used (by adding external components) to obtain adjustable output voltages and currents. USM LM7805 can be used as fixed voltage regulator in a wide range of applications where local voltage regulation is preferred for elimination of noise and distribution problems associated with single-point regulation. Provided, USM LM7805 can deliver up to 1.5A output current. USM LM7805 is a high reliability 3-terminal positive voltage regulator designed for military and space applications, with built in internal current limiting, thermal shutdown and safe-area compensation for maximum flexibility and safety. High reliability military and space applications Stresses beyond listed absolute maximum ratings may cause permanent damage to the device. ONLY Proper die handling equipment and procedures should be employed. Storage Temperature Range TSTG -65 to +150 ☌ Operating Junction Temperature Range TJ -55 to 150 ☌ Internal Power Dissipation (Note1) PD internally limited W The backside of the die is coated with 0.5µm GOLD, which makes it compatible with AuSi or AuGe die attach. The bond pad metallization is standard 1µm Aluminum. USM LM7805 is available in die form only.
Input bypassing is needed only if the regulator is located far from the filter capacitor of the power supply.
It is not necessary to bypass the output, although this does improve transient response. USM LM7805 can also be used (by adding external components) to obtain adjustable output voltages and currents.
With adequate heat sinking provided, USM LM7805 can deliver up to 1.5A output current.
PRODUCT DESCRIPTION AND SHORT APPLICATION NOTE High reliability military and space application In DIE form, this device is an excellent selection for many chip and wire HYBRID CIRCUITS HIGH RELIABILITY 5V POSITIVE VOLTAGE REGULATOR DIE FOR HYBRID CIRCUITS USM7805 is a high reliability 5 V volt voltage regulator version for military and space applications, HIGH RELIABILITY USM LM7805 3-terminal positive voltage regulator for military and space applications, hybrid circuits and microwave power amplifiers known good die LM series from US Microwaves
